Geoprocessing Output Parameter

Property

Description

Name of the Geoprocessing parameter

Name of the Geoprocessing output parameter which should be pre-initialized with a given value.

Note: Open the geoprocessing task REST URL in a browser in order to identify the available geoprocessing parameters easily. Example: http://<myserver>/ArcGIS/rest/services/<myService>/GPServer/<geoprocessing task>

Identify geoprocessing parameter name in the ArcGIS REST services directory

Alias name of the Geoprocessing parameter

Alias name of the Geoprocessing output parameter, which is shown within the Table of contents, as well as in the caption of a result list.

User may change?

Specifies whether the user may change or set the input parameter value.

Parse Hyperlinks?

If this parameter is set to true WebOffice will search for hyperlinks in the Resultset and they will be displayed as Hyperlinks in the GUI.

Hyperlink Columnnames

A Comma separated List of Columnnames which should be searched for Hyperlinks. If the list is left empty all columns will be searched for Hyperlinks, it is recommended to enter the columnnames if the Html Client is being used, for the Core client this setting is not necessary. This setting should only be used with Parse Hyperlinks set on Yes. The names are not case sensitive.

Example: Homepage
