Title

Property

Description

Field caption

Caption in print template. Standard ratios are applied if there are no language-specific terms are specified.

Field value

Value in print template.

Note: If "User may change?" is set to "Yes" you may also provide a list of possible values to the user. Use the "|" symbol as delimiter between the possible values, e.g. title 1|title 2. The first value will be the default value. If you want to provide several values but no default value, start your listing with a "|" symbol, e.g. |title 1|title 2.

Note: You can also use placeholders for the print title field value:

•<project> will be replaced with the name of the project

•<view> will add the currently active map view

ID of field caption

The ID for this predefined function field is always title_caption.

ID of field value

The ID for this predefined function field is always title_value.

User may change?

Specifies whether the user my change or set the value in the print tool form (Yes) or not (No).

Append project to title?

Specifies whether the name of the project shall be appended (separated by a dash) to the defined title.

Note: The project name refers to the placeholder <project>.

Append mapview to title?

Specifies whether the name of the map view shall be appended (separated by a dash) to the defined title.

Note: The map view refers to the placeholder <view>.
