Inserting Another Feature Map
In addition to the DKM feature map, a second feature map is added with a different map view. To do this, a second feature map is added from the toolbar to the existing FEATUREMAP-Data band from the toolbar. Within a FEATUREMAP-Databand can contain several maps. The advantage of this is that the assignment to the main data tape only has to be made once.
Feature Map Properties - General
Name |
The Feature- is called the Overview. |
Resolution |
The resolution is set to 300 dpi. |
GeoOffice map view |
For the feature map Zoning the GeoOffice map view Zoning is assigned. |
Rotation |
No rotation is defined. If a rotation is set on the data frame in the project, then this rotation is automatically applied. |
Display scale as scale value in the map |
This option is not activated because the scale is added via a scale number. |
Feature Map Properties - Tab "Scale Settings"
A fixed scale of 1:2000 is defined.
